Reference documentation for deal.II version 9.3.0

#include <deal.II/hp/fe_collection.h>
Classes
struct  DefaultHierarchy
Public Member Functions
FECollection ()
FECollection (const FiniteElement< dim, spacedim > &fe)
template<class... FETypes>
FECollection (const FETypes &... fes)
FECollection (const std::vector< const FiniteElement< dim, spacedim > *> &fes)
FECollection (const FECollection< dim, spacedim > &)=default
FECollection (FECollection< dim, spacedim > &&) noexcept(std::is_nothrow_move_constructible< std::vector< std::shared_ptr< const FiniteElement< dim, spacedim >>>>::value &&std::is_nothrow_move_constructible< std::function< unsigned int(const typename hp::FECollection< dim, spacedim > &, const unsigned int)>>::value)=default
FECollection< dim, spacedim > &  operator= (FECollection< dim, spacedim > &&)=default
bool  operator== (const FECollection< dim, spacedim > &fe_collection) const
bool  operator!= (const FECollection< dim, spacedim > &fe_collection) const
void  push_back (const FiniteElement< dim, spacedim > &new_fe)
unsigned int  n_components () const
unsigned int  n_blocks () const
unsigned int  max_degree () const
unsigned int  max_dofs_per_vertex () const
unsigned int  max_dofs_per_line () const
unsigned int  max_dofs_per_quad () const
unsigned int  max_dofs_per_hex () const
unsigned int  max_dofs_per_face () const
unsigned int  max_dofs_per_cell () const
bool  hp_constraints_are_implemented () const
std::set< unsigned int >  find_common_fes (const std::set< unsigned int > &fes, const unsigned int codim=0) const
std::set< unsigned int >  find_enclosing_fes (const std::set< unsigned int > &fes, const unsigned int codim=0) const
unsigned int  find_dominating_fe (const std::set< unsigned int > &fes, const unsigned int codim=0) const
unsigned int  find_dominated_fe (const std::set< unsigned int > &fes, const unsigned int codim=0) const
unsigned int  find_dominating_fe_extended (const std::set< unsigned int > &fes, const unsigned int codim=0) const
unsigned int  find_dominated_fe_extended (const std::set< unsigned int > &fes, const unsigned int codim=0) const
void  set_hierarchy (const std::function< unsigned int(const typename hp::FECollection< dim, spacedim > &, const unsigned int)> &next, const std::function< unsigned int(const typename hp::FECollection< dim, spacedim > &, const unsigned int)> &prev)
void  set_default_hierarchy ()
std::vector< unsigned int >  get_hierarchy_sequence (const unsigned int fe_index=0) const
unsigned int  next_in_hierarchy (const unsigned int fe_index) const
unsigned int  previous_in_hierarchy (const unsigned int fe_index) const
ComponentMask  component_mask (const FEValuesExtractors::Scalar &scalar) const
ComponentMask  component_mask (const FEValuesExtractors::Vector &vector) const
ComponentMask  component_mask (const FEValuesExtractors::SymmetricTensor< 2 > &sym_tensor) const
ComponentMask  component_mask (const BlockMask &block_mask) const
BlockMask  block_mask (const FEValuesExtractors::Scalar &scalar) const
BlockMask  block_mask (const FEValuesExtractors::Vector &vector) const
BlockMask  block_mask (const FEValuesExtractors::SymmetricTensor< 2 > &sym_tensor) const
BlockMask  block_mask (const ComponentMask &component_mask) const
void  push_back (const std::shared_ptr< const FiniteElement< dim, spacedim > > &new_entry)
const FiniteElement< dim, spacedim > &  operator[] (const unsigned int index) const
unsigned int  size () const
std::size_t  memory_consumption () const
template<class Archive >
void  serialize (Archive &ar, const unsigned int version)
Subscriptor functionality
Classes derived from Subscriptor provide a facility to subscribe to this object. This is mostly used by the SmartPointer class.
void  subscribe (std::atomic< bool > *const validity, const std::string &identifier="") const
void  unsubscribe (std::atomic< bool > *const validity, const std::string &identifier="") const
unsigned int  n_subscriptions () const
template<typename StreamType >
void  list_subscribers (StreamType &stream) const
void  list_subscribers () const
Static Public Member Functions
static ::ExceptionBase &  ExcInUse (int arg1, std::string arg2, std::string arg3)
static ::ExceptionBase &  ExcNoSubscriber (std::string arg1, std::string arg2)
Exceptions
static ::ExceptionBase &  ExcNoFiniteElements ()
Private Attributes
std::function< unsigned int(const typename hp::FECollection< dim, spacedim > &, const unsigned int)>  hierarchy_next
std::function< unsigned int(const typename hp::FECollection< dim, spacedim > &, const unsigned int)>  hierarchy_prev
This class acts as a collection of finite element objects used in the DoFHandler.
It implements the concepts stated in the hpCollections module described in the doxygen documentation.
In addition to offering access to the elements of the collection, this class provides access to the maximal number of degrees of freedom per vertex, line, etc, to allow allocation of as much memory as is necessary in the worst case when using the finite elements associated with the cells of a triangulation.
This class has not yet been implemented for the use in the codimension one case (spacedim != dim
).
Definition at line 53 of file fe_collection.h.
hp::FECollection< dim, spacedim >::FECollection  (  )
Default constructor. Leads to an empty collection that can later be filled using push_back(). Establishes a hierarchy of finite elements corresponding to their index in the collection.
Definition at line 240 of file fe_collection.cc.

explicit
Conversion constructor. This constructor creates a FECollection from a single finite element. More finite element objects can be added with push_back(), if desired, though it would probably be clearer to add all mappings the same way.
Definition at line 248 of file fe_collection.cc.

explicit
Constructor. This constructor creates a FECollection from one or more finite element objects passed to the constructor. For this call to be valid, all arguments need to be of types derived from class FiniteElement<dim,spacedim>.
Definition at line 768 of file fe_collection.h.
hp::FECollection< dim, spacedim >::FECollection  (  const std::vector< const FiniteElement< dim, spacedim > *> &  fes  )
Constructor. Same as above but for any number of elements. Pointers to the elements are passed in a vector to this constructor. As above, the finite element objects pointed to by the argument are not actually used other than to create copies internally. Consequently, you can delete these pointers immediately again after calling this constructor.
Definition at line 258 of file fe_collection.cc.

default
Copy constructor.

defaultnoexcept
Move constructor.

default
Move assignment operator.

inline
Equality comparison operator. All stored FiniteElement objects are compared in order.
Definition at line 808 of file fe_collection.h.

inline
Nonequality comparison operator. All stored FiniteElement objects are compared in order.
Definition at line 826 of file fe_collection.h.
void hp::FECollection< dim, spacedim >::push_back  (  const FiniteElement< dim, spacedim > &  new_fe  )
Add a finite element. This function generates a copy of the given element, i.e. you can do things like push_back(FE_Q<dim>(1));
. The internal copy is later destroyed by this object upon destruction of the entire collection.
When a new element is added, it needs to have the same number of vector components as all other elements already in the collection.
Definition at line 273 of file fe_collection.cc.

inline
Return the number of vector components of the finite elements in this collection. This number must be the same for all elements in the collection.
This function calls FiniteElement::n_components. See the glossary for more information.
Definition at line 788 of file fe_collection.h.
unsigned int hp::FECollection< dim, spacedim >::n_blocks  (  )  const
Return the number of vector blocks of the finite elements in this collection. While this class ensures that all elements stored in it have the same number of vector components, there is no such guarantees for the number of blocks each element is made up of (an element may have fewer blocks than vector components; see the glossary for more information). For example, you may have an FECollection object that stores one copy of an FESystem with dim
FE_Q objects and one copy of an FE_RaviartThomas element. Both have dim
vector components but while the former has dim
blocks the latter has only one. Consequently, this function will throw an assertion if the number of blocks is not the same for all elements. If they are the same, this function returns the result of FiniteElement::n_blocks().
Definition at line 566 of file fe_collection.cc.
unsigned int hp::FECollection< dim, spacedim >::max_degree  (  )  const
Return the maximum of values returned by FiniteElement::get_degree() over all elements of this collection.
Definition at line 835 of file fe_collection.h.
unsigned int hp::FECollection< dim, spacedim >::max_dofs_per_vertex  (  )  const
Return the maximal number of degrees of freedom per vertex over all elements of this collection.
Definition at line 850 of file fe_collection.h.
unsigned int hp::FECollection< dim, spacedim >::max_dofs_per_line  (  )  const
Return the maximal number of degrees of freedom per line over all elements of this collection.
Definition at line 865 of file fe_collection.h.
unsigned int hp::FECollection< dim, spacedim >::max_dofs_per_quad  (  )  const
Return the maximal number of degrees of freedom per quad over all elements of this collection.
Definition at line 880 of file fe_collection.h.
unsigned int hp::FECollection< dim, spacedim >::max_dofs_per_hex  (  )  const
Return the maximal number of degrees of freedom per hex over all elements of this collection.
Definition at line 895 of file fe_collection.h.
unsigned int hp::FECollection< dim, spacedim >::max_dofs_per_face  (  )  const
Return the maximal number of degrees of freedom per face over all elements of this collection.
Definition at line 910 of file fe_collection.h.
unsigned int hp::FECollection< dim, spacedim >::max_dofs_per_cell  (  )  const
Return the maximal number of degrees of freedom per cell over all elements of this collection.
Definition at line 925 of file fe_collection.h.
bool hp::FECollection< dim, spacedim >::hp_constraints_are_implemented  (  )  const
Return whether all elements in this collection implement the hanging node constraints in the new way, which has to be used to make elements "hpcompatible". If this is not the case, the function returns false, which implies, that at least one element in the FECollection does not support the new face interface constraints. On the other hand, if this method does return true, this does not imply that the hpmethod will work!
This behavior is related to the fact, that FiniteElement classes, which provide the new style hanging node constraints might still not provide them for all possible cases. If FE_Q and FE_RaviartThomas elements are included in the FECollection and both properly implement the get_face_interpolation_matrix method, this method will return true. But the get_face_interpolation_matrix might still fail to find an interpolation matrix between these two elements.
Definition at line 939 of file fe_collection.h.
std::set< unsigned int > hp::FECollection< dim, spacedim >::find_common_fes  (  const std::set< unsigned int > &  fes,
const unsigned int  codim = 0

)  const
Return the indices of finite elements in this FECollection that dominate all elements associated with the provided set of indices fes
.
You may find information about the domination behavior of finite elements in their respective class documentation or in the implementation of their inherited member function FiniteElement::compare_for_domination(). Consider that a finite element may or may not dominate itself (e.g. FE_Nothing elements).
For example, if a FECollection consists of {FE_Q(1),FE_Q(2),FE_Q(3),FE_Q(4)}
elements and we are looking for the finite elements that dominate the middle elements of this collection (i.e., fes
is {1,2}
), then the answer is {FE_Q(1),FE_Q(2)
and therefore this function will return their indices in the FECollection, namely {0,1}
.
The codim
parameter describes the codimension of the investigated subspace and specifies that it is subject to this comparison. See FiniteElement::compare_for_domination() for more information.
Definition at line 27 of file fe_collection.cc.
std::set< unsigned int > hp::FECollection< dim, spacedim >::find_enclosing_fes  (  const std::set< unsigned int > &  fes,
const unsigned int  codim = 0

)  const
Return the indices of finite elements in this FECollection that are dominated by all elements associated with the provided set of indices fes
.
You may find information about the domination behavior of finite elements in their respective class documentation or in the implementation of their inherited member function FiniteElement::compare_for_domination(). Consider that a finite element may or may not dominate itself (e.g. FE_Nothing elements).
For example, if a FECollection consists of {FE_Q(1),FE_Q(2),FE_Q(3),FE_Q(4)}
elements and we are looking for the finite elements that are dominated by the middle elements of this collection (i.e., fes
is {1,2}
), then the answer is {FE_Q(3),FE_Q(4)
and therefore this function will return their indices in the FECollection, namely {2,3}
.
The codim
parameter describes the codimension of the investigated subspace and specifies that it is subject to this comparison. See FiniteElement::compare_for_domination() for more information.
Definition at line 67 of file fe_collection.cc.
unsigned int hp::FECollection< dim, spacedim >::find_dominating_fe  (  const std::set< unsigned int > &  fes,
const unsigned int  codim = 0

)  const
Return the index of a finite element from the provided set of indices fes
that dominates all other elements of this very set.
You may find information about the domination behavior of finite elements in their respective class documentation or in the implementation of their inherited member function FiniteElement::compare_for_domination(). Consider that a finite element may or may not dominate itself (e.g. FE_Nothing elements).
If this set consists of exactly one element, we consider it to be the dominating one and return its corresponding index. Further, if the function is not able to find a finite element at all, it returns numbers::invalid_unsigned_int.
For example, if a FECollection consists of {FE_Q(1),FE_Q(2),FE_Q(3),FE_Q(4)}
elements and we are looking for the dominating finite element among the middle elements of this collection (i.e., fes
is {1,2}
), then the answer is FE_Q(2) and therefore this function will return its index in the FECollection, namely 1
.
It is of course possible that there is more than one element that dominates all selected elements. For example, if the collection consists of {FE_Q(1),FE_Q(1),FE_Q(2),FE_Q(2)}
and fes
covers all indices, then one could return zero or one. In that case, the function returns either 0
or 1
since there is no tiebreaker between the two.
The codim
parameter describes the codimension of the investigated subspace and specifies that it is subject to this comparison. See FiniteElement::compare_for_domination() for more information.
Definition at line 107 of file fe_collection.cc.
unsigned int hp::FECollection< dim, spacedim >::find_dominated_fe  (  const std::set< unsigned int > &  fes,
const unsigned int  codim = 0

)  const
Return the index of a finite element from the provided set of indices fes
that is dominated by all other elements of this very set.
You may find information about the domination behavior of finite elements in their respective class documentation or in the implementation of their inherited member function FiniteElement::compare_for_domination(). Consider that a finite element may or may not dominate itself (e.g. FE_Nothing elements).
If this set consists of exactly one element, we consider it to be the dominated one and return its corresponding index. Further, if the function is not able to find a finite element at all, it returns numbers::invalid_unsigned_int.
For example, if a FECollection consists of {FE_Q(1),FE_Q(2),FE_Q(3),FE_Q(4)}
elements and we are looking for the dominated finite element among the middle elements of this collection (i.e., fes
is {1,2}
), then the answer is FE_Q(3) and therefore this function will return its index in the FECollection, namely 2
.
It is of course possible that there is more than one element that is dominated by all selected elements. For example, if the collection consists of {FE_Q(1),FE_Q(1),FE_Q(2),FE_Q(2)}
and fes
covers all indices, then one could return two or three. In that case, the function returns either 2
or 3
since there is no tiebreaker between the two.
The codim
parameter describes the codimension of the investigated subspace and specifies that it is subject to this comparison. See FiniteElement::compare_for_domination() for more information.
Definition at line 154 of file fe_collection.cc.
unsigned int hp::FECollection< dim, spacedim >::find_dominating_fe_extended  (  const std::set< unsigned int > &  fes,
const unsigned int  codim = 0

)  const
Return the index of a finite element from the provided set of indices fes
that dominates all other elements of this very set. If we do not succeed, we extend our search on the whole collection by picking the least dominating one, which is the element that describes the largest finite element space of which all of the finite elements of the provided set fes
are part of.
You may find information about the domination behavior of finite elements in their respective class documentation or in the implementation of their inherited member function FiniteElement::compare_for_domination(). Consider that a finite element may or may not dominate itself (e.g. FE_Nothing elements).
If this set consists of exactly one element, we consider it to be the dominated one and return its corresponding index. Further, if the function is not able to find a finite element at all, it returns numbers::invalid_unsigned_int.
The codim
parameter describes the codimension of the investigated subspace and specifies that it is subject to this comparison. See FiniteElement::compare_for_domination() for more information.
Definition at line 201 of file fe_collection.cc.
unsigned int hp::FECollection< dim, spacedim >::find_dominated_fe_extended  (  const std::set< unsigned int > &  fes,
const unsigned int  codim = 0

)  const
Return the index of a finite element from the provided set of indices fes
that is dominated by all other elements of this very set. If we do not succeed, we extend our search on the whole collection by picking the most dominated one, which is the element that describes the smallest finite element space which includes all finite elements of the provided set fes
.
You may find information about the domination behavior of finite elements in their respective class documentation or in the implementation of their inherited member function FiniteElement::compare_for_domination(). Consider that a finite element may or may not dominate itself (e.g. FE_Nothing elements).
If this set consists of exactly one element, we consider it to be the dominating one and return its corresponding index. Further, if the function is not able to find a finite element at all, it returns numbers::invalid_unsigned_int.
The codim
parameter describes the codimension of the investigated subspace and specifies that it is subject to this comparison. See FiniteElement::compare_for_domination() for more information.
Definition at line 221 of file fe_collection.cc.
void hp::FECollection< dim, spacedim >::set_hierarchy  (  const std::function< unsigned int(const typename hp::FECollection< dim, spacedim > &, const unsigned int)> &  next,
const std::function< unsigned int(const typename hp::FECollection< dim, spacedim > &, const unsigned int)> &  prev
)
Set functions determining the hierarchy of finite elements, i.e. a function next
that returns the index of the finite element following the given one, and a function prev
returning the preceding one.
Both functions expect an hp::FECollection to be passed along with a finite element index, on whose basis the new index will be found and returned.
Definition at line 291 of file fe_collection.cc.
void hp::FECollection< dim, spacedim >::set_default_hierarchy  (  )
Set the default hierarchy corresponding to the index of each finite element in the collection.
This default hierarchy is established with functions DefaultHierarchy::next_index() and DefaultHierarchy::previous_index().
Definition at line 308 of file fe_collection.cc.
std::vector< unsigned int > hp::FECollection< dim, spacedim >::get_hierarchy_sequence  (  const unsigned int  fe_index = 0  )  const
Returns a sequence of FE indices that corresponds to the registered hierarchy in ascending order, i.e., FE indices are sorted from lowest to highest level.
Multiple sequences of FE indices are possible with a single custom hierarchy that can be registered with set_hierarchy(). This function will return the sequence that contains the userprovided index fe_index
which could be located anywhere inside the sequence. The default hierarchy set via set_default_hierarchy(), which corresponds to FE indices in ascending order, consists of only one sequence.
This function can be used, for example, to verify that your provided hierarchy covers all elements in the desired order.
Only one sequence of FE indices exists if the size of the returned container equals the number of elements of this object, i.e., FECollection::size().
Definition at line 319 of file fe_collection.cc.
unsigned int hp::FECollection< dim, spacedim >::next_in_hierarchy  (  const unsigned int  fe_index  )  const
Function returning the index of the finite element following the given fe_index
in hierarchy.
By default, the index succeeding fe_index
will be returned. If fe_index
already corresponds to the last index, the last index will be returned. A custom hierarchy can be supplied via the member function set_hierachy().
Definition at line 365 of file fe_collection.cc.
unsigned int hp::FECollection< dim, spacedim >::previous_in_hierarchy  (  const unsigned int  fe_index  )  const
Function returning the index of the finite element preceding the given fe_index
in hierarchy.
By default, the index preceding fe_index
will be returned. If fe_index
already corresponds to the first index, the first index will be returned. A custom hierarchy can be supplied via the member function set_hierachy().
Definition at line 380 of file fe_collection.cc.
ComponentMask hp::FECollection< dim, spacedim >::component_mask  (  const FEValuesExtractors::Scalar &  scalar  )  const
Return a component mask with as many elements as this object has vector components and of which exactly the one component is true that corresponds to the given argument.
scalar  An object that represents a single scalar vector component of this finite element.
Definition at line 395 of file fe_collection.cc.
ComponentMask hp::FECollection< dim, spacedim >::component_mask  (  const FEValuesExtractors::Vector &  vector  )  const
Return a component mask with as many elements as this object has vector components and of which exactly the dim
components are true that correspond to the given argument.
vector  An object that represents dim vector components of this finite element.
Definition at line 415 of file fe_collection.cc.
ComponentMask hp::FECollection< dim, spacedim >::component_mask  (  const FEValuesExtractors::SymmetricTensor< 2 > &  sym_tensor  )  const
Return a component mask with as many elements as this object has vector components and of which exactly the dim*(dim+1)/2
components are true that correspond to the given argument.
sym_tensor  An object that represents dim*(dim+1)/2 components of this finite element that are jointly to be interpreted as forming a symmetric tensor.
Definition at line 435 of file fe_collection.cc.
ComponentMask hp::FECollection< dim, spacedim >::component_mask  (  const BlockMask &  block_mask  )  const
Given a block mask (see this glossary entry ), produce a component mask (see this glossary entry ) that represents the components that correspond to the blocks selected in the input argument. This is essentially a conversion operator from BlockMask to ComponentMask.
block_mask  The mask that selects individual blocks of the finite element
Definition at line 455 of file fe_collection.cc.
BlockMask hp::FECollection< dim, spacedim >::block_mask  (  const FEValuesExtractors::Scalar &  scalar  )  const
Return a block mask with as many elements as this object has blocks and of which exactly the one component is true that corresponds to the given argument. See the glossary for more information.
scalar  An object that represents a single scalar vector component of this finite element.
Definition at line 476 of file fe_collection.cc.
BlockMask hp::FECollection< dim, spacedim >::block_mask  (  const FEValuesExtractors::Vector &  vector  )  const
Return a component mask with as many elements as this object has vector components and of which exactly the dim
components are true that correspond to the given argument. See the glossary for more information.
vector  An object that represents dim vector components of this finite element.
Definition at line 498 of file fe_collection.cc.
BlockMask hp::FECollection< dim, spacedim >::block_mask  (  const FEValuesExtractors::SymmetricTensor< 2 > &  sym_tensor  )  const
Return a component mask with as many elements as this object has vector components and of which exactly the dim*(dim+1)/2
components are true that correspond to the given argument. See the glossary for more information.
sym_tensor  An object that represents dim*(dim+1)/2 components of this finite element that are jointly to be interpreted as forming a symmetric tensor.
Definition at line 520 of file fe_collection.cc.
BlockMask hp::FECollection< dim, spacedim >::block_mask  (  const ComponentMask &  component_mask  )  const
Given a component mask (see this glossary entry ), produce a block mask (see this glossary entry ) that represents the blocks that correspond to the components selected in the input argument. This is essentially a conversion operator from ComponentMask to BlockMask.
component_mask  The mask that selects individual components of the finite element
Definition at line 543 of file fe_collection.cc.

inherited
Add a new object.
Definition at line 100 of file collection.h.

inlineinherited
Return the object which was specified by the user for the active FE index which is provided as a parameter to this method.
index
must be between zero and the number of elements of the collection. Definition at line 117 of file collection.h.

inlineinherited
Return the number of objects stored in this container.
Definition at line 109 of file collection.h.

inherited
Determine an estimate for the memory consumption (in bytes) of this object.
Definition at line 91 of file collection.h.

inherited
Subscribes a user of the object by storing the pointer validity
. The subscriber may be identified by text supplied as identifier
.
Definition at line 136 of file subscriptor.cc.

inherited
Unsubscribes a user from the object.
identifier
and the validity
pointer must be the same as the one supplied to subscribe(). Definition at line 156 of file subscriptor.cc.

inlineinherited
Return the present number of subscriptions to this object. This allows to use this class for reference counted lifetime determination where the last one to unsubscribe also deletes the object.
Definition at line 301 of file subscriptor.h.

inlineinherited
List the subscribers to the input stream
.
Definition at line 318 of file subscriptor.h.

inherited
List the subscribers to deallog
.
Definition at line 204 of file subscriptor.cc.

inlineinherited
Read or write the data of this object to or from a stream for the purpose of serialization using the BOOST serialization library.
This function does not actually serialize any of the member variables of this class. The reason is that what this class stores is only who subscribes to this object, but who does so at the time of storing the contents of this object does not necessarily have anything to do with who subscribes to the object when it is restored. Consequently, we do not want to overwrite the subscribers at the time of restoring, and then there is no reason to write the subscribers out in the first place.
Definition at line 310 of file subscriptor.h.

private
Function returning the index of the finite element following the given one in hierarchy.
Definition at line 751 of file fe_collection.h.

private
Function returning the index of the finite element preceding the given one in hierarchy.
Definition at line 759 of file fe_collection.h.
