Reference documentation for deal.II version 9.5.0

#include <deal.II/lac/solver_richardson.h>
Classes
struct  AdditionalData
Public Types
using  vector_type = VectorType
Public Member Functions
SolverRichardson (SolverControl &cn, VectorMemory< VectorType > &mem, const AdditionalData &data=AdditionalData())
SolverRichardson (SolverControl &cn, const AdditionalData &data=AdditionalData())
virtual  ~SolverRichardson () override=default
template<typename MatrixType , typename PreconditionerType >
void  solve (const MatrixType &A, VectorType &x, const VectorType &b, const PreconditionerType &preconditioner)
template<typename MatrixType , typename PreconditionerType >
void  Tsolve (const MatrixType &A, VectorType &x, const VectorType &b, const PreconditionerType &preconditioner)
void  set_omega (const double om=1.)
virtual void  print_vectors (const unsigned int step, const VectorType &x, const VectorType &r, const VectorType &d) const
boost::signals2::connection  connect (const std::function< SolverControl::State(const unsigned int iteration, const double check_value, const VectorType ¤t_iterate)> &slot)
template<class Archive >
void  serialize (Archive &ar, const unsigned int version)
Subscriptor functionality
Classes derived from Subscriptor provide a facility to subscribe to this object. This is mostly used by the SmartPointer class.
void  subscribe (std::atomic< bool > *const validity, const std::string &identifier="") const
void  unsubscribe (std::atomic< bool > *const validity, const std::string &identifier="") const
unsigned int  n_subscriptions () const
template<typename StreamType >
void  list_subscribers (StreamType &stream) const
void  list_subscribers () const
Static Public Member Functions
static ::ExceptionBase &  ExcInUse (int arg1, std::string arg2, std::string arg3)
static ::ExceptionBase &  ExcNoSubscriber (std::string arg1, std::string arg2)
Protected Member Functions
virtual VectorType::value_type  criterion (const VectorType &r, const VectorType &d) const
Protected Attributes
AdditionalData  additional_data
GrowingVectorMemory< VectorType >  static_vector_memory
VectorMemory< VectorType > &  memory
boost::signals2::signal< SolverControl::State(const unsigned int iteration, const double check_value, const VectorType ¤t_iterate), StateCombiner >  iteration_status
Private Types
using  map_value_type = decltype(counter_map)::value_type
using  map_iterator = decltype(counter_map)::iterator
Private Member Functions
void  check_no_subscribers () const noexcept
Private Attributes
std::atomic< unsigned int >  counter
std::map< std::string, unsigned int >  counter_map
std::vector< std::atomic< bool > * >  validity_pointers
const std::type_info *  object_info
Static Private Attributes
static std::mutex  mutex
Implementation of the preconditioned Richardson iteration method. The stopping criterion is the norm of the residual.
For the requirements on matrices and vectors in order to work with this class, see the documentation of the Solver base class.
Like all other solver classes, this class has a local structure called AdditionalData
which is used to pass additional parameters to the solver, like damping parameters or the number of temporary vectors. We use this additional structure instead of passing these values directly to the constructor because this makes the use of the SolverSelector
and other classes much easier and guarantees that these will continue to work even if number or type of the additional parameters for a certain solver changes.
For the Richardson method, the additional data is the damping parameter, which is the only content of the AdditionalData
structure. By default, the constructor of the structure sets it to one.
The solve() function of this class uses the mechanism described in the Solver base class to determine convergence. This mechanism can also be used to observe the progress of the iteration.
Definition at line 64 of file solver_richardson.h.

inherited

privateinherited
The data type used in counter_map.
Definition at line 230 of file subscriptor.h.

privateinherited
The iterator type used in counter_map.
Definition at line 235 of file subscriptor.h.
SolverRichardson< VectorType >::SolverRichardson  (  SolverControl &  cn,
VectorMemory< VectorType > &  mem,
const AdditionalData &  data = AdditionalData()

)
Constructor.
SolverRichardson< VectorType >::SolverRichardson  (  SolverControl &  cn,
const AdditionalData &  data = AdditionalData()

)
Constructor. Use an object of type GrowingVectorMemory as a default to allocate memory.

overridevirtualdefault
Virtual destructor.
void SolverRichardson< VectorType >::solve  (  const MatrixType &  A,
VectorType &  x,
const VectorType &  b,
const PreconditionerType &  preconditioner
)
Solve the linear system \(Ax=b\) for x.
void SolverRichardson< VectorType >::Tsolve  (  const MatrixType &  A,
VectorType &  x,
const VectorType &  b,
const PreconditionerType &  preconditioner
)
Solve \(A^Tx=b\) for \(x\).
void SolverRichardson< VectorType >::set_omega  (  const double  om = 1.  )
Set the dampingcoefficient. Default is 1., i.e. no damping.

virtual
Interface for derived class. This function gets the current iteration vector, the residual and the update vector in each step. It can be used for graphical output of the convergence history.

protectedvirtual
Implementation of the computation of the norm of the residual. Depending on the flags given to the solver, the default implementation of this function uses either the actual residual, r
, or the preconditioned residual, d
.

inherited
Connect a function object that will be called periodically within iterative solvers. This function is used to attach monitors to iterative solvers, either to determine when convergence has happened, or simply to observe the progress of an iteration. See the documentation of this class for more information.
slot  A function object specified here will, with each call, receive the number of the current iteration, the value that is used to check for convergence (typically the residual of the current iterate with respect to the linear system to be solved) and the currently best available guess for the current iterate. Note that some solvers do not update the approximate solution in every iteration but only after convergence or failure has been determined (GMRES is an example); in such cases, the vector passed as the last argument to the signal is simply the best approximate at the time the signal is called, but not the vector that will be returned if the signal's return value indicates that the iteration should be terminated. The function object must return a SolverControl::State value that indicates whether the iteration should continue, has failed, or has succeeded. The results of all connected functions will then be combined to determine what should happen with the iteration.

inherited
Subscribes a user of the object by storing the pointer validity
. The subscriber may be identified by text supplied as identifier
.
Definition at line 136 of file subscriptor.cc.

inherited
Unsubscribes a user from the object.
identifier
and the validity
pointer must be the same as the one supplied to subscribe(). Definition at line 156 of file subscriptor.cc.

inlineinherited
Return the present number of subscriptions to this object. This allows to use this class for reference counted lifetime determination where the last one to unsubscribe also deletes the object.
Definition at line 300 of file subscriptor.h.

inlineinherited
List the subscribers to the input stream
.
Definition at line 317 of file subscriptor.h.

inherited
List the subscribers to deallog
.
Definition at line 204 of file subscriptor.cc.

inlineinherited
Read or write the data of this object to or from a stream for the purpose of serialization using the BOOST serialization library.
This function does not actually serialize any of the member variables of this class. The reason is that what this class stores is only who subscribes to this object, but who does so at the time of storing the contents of this object does not necessarily have anything to do with who subscribes to the object when it is restored. Consequently, we do not want to overwrite the subscribers at the time of restoring, and then there is no reason to write the subscribers out in the first place.
Definition at line 309 of file subscriptor.h.

privatenoexceptinherited
Check that there are no objects subscribing to this object. If this check passes then it is safe to destroy the current object. It this check fails then this function will either abort or print an error message to deallog (by using the AssertNothrow mechanism), but will not throw an exception.
Definition at line 53 of file subscriptor.cc.

protected
Control parameters.
Definition at line 158 of file solver_richardson.h.

mutableprotectedinherited

protectedinherited

protectedinherited
A signal that iterative solvers can execute at the end of every iteration (or in an otherwise periodic fashion) to find out whether we should continue iterating or not. The signal may call one or more slots that each will make this determination by themselves, and the result over all slots (function calls) will be determined by the StateCombiner object.
The arguments passed to the signal are (i) the number of the current iteration; (ii) the value that is used to determine convergence (oftentimes the residual, but in other cases other quantities may be used as long as they converge to zero as the iterate approaches the solution of the linear system); and (iii) a vector that corresponds to the current best guess for the solution at the point where the signal is called. Note that some solvers do not update the approximate solution in every iteration but only after convergence or failure has been determined (GMRES is an example); in such cases, the vector passed as the last argument to the signal is simply the best approximate at the time the signal is called, but not the vector that will be returned if the signal's return value indicates that the iteration should be terminated.

mutableprivateinherited
Store the number of objects which subscribed to this object. Initially, this number is zero, and upon destruction it shall be zero again (i.e. all objects which subscribed should have unsubscribed again).
The creator (and owner) of an object is counted in the map below if HE manages to supply identification.
We use the mutable
keyword in order to allow subscription to constant objects also.
This counter may be read from and written to concurrently in multithreaded code: hence we use the std::atomic
class template.
Definition at line 219 of file subscriptor.h.

mutableprivateinherited
In this map, we count subscriptions for each different identification string supplied to subscribe().
Definition at line 225 of file subscriptor.h.

mutableprivateinherited
In this vector, we store pointers to the validity bool in the SmartPointer objects that subscribe to this class.
Definition at line 241 of file subscriptor.h.

mutableprivateinherited
Pointer to the typeinfo object of this object, from which we can later deduce the class name. Since this information on the derived class is neither available in the destructor, nor in the constructor, we obtain it in between and store it here.
Definition at line 249 of file subscriptor.h.

staticprivateinherited
A mutex used to ensure data consistency when printing out the list of subscribers.
Definition at line 271 of file subscriptor.h.
