Reference documentation for deal.II version 9.5.0

#include <deal.II/base/polynomial.h>
Public Member Functions
Lobatto (const unsigned int p=0)
double  value (const double x) const
void  value (const double x, std::vector< double > &values) const
void  value (const Number2 x, const unsigned int n_derivatives, Number2 *values) const
void  values_of_array (const std::array< Number2, n_entries > &points, const unsigned int n_derivatives, std::array< Number2, n_entries > *values) const
unsigned int  degree () const
void  scale (const double factor)
void  shift (const number2 offset)
Polynomial< double >  derivative () const
Polynomial< double >  primitive () const
Polynomial< double > &  operator*= (const double s)
Polynomial< double > &  operator*= (const Polynomial< double > &p)
Polynomial< double > &  operator+= (const Polynomial< double > &p)
Polynomial< double > &  operator= (const Polynomial< double > &p)
bool  operator== (const Polynomial< double > &p) const
void  print (std::ostream &out) const
void  serialize (Archive &ar, const unsigned int version)
virtual std::size_t  memory_consumption () const
Subscriptor functionality
Classes derived from Subscriptor provide a facility to subscribe to this object. This is mostly used by the SmartPointer class.
void  subscribe (std::atomic< bool > *const validity, const std::string &identifier="") const
void  unsubscribe (std::atomic< bool > *const validity, const std::string &identifier="") const
unsigned int  n_subscriptions () const
template<typename StreamType >
void  list_subscribers (StreamType &stream) const
void  list_subscribers () const
Static Public Member Functions
static std::vector< Polynomial< double > >  generate_complete_basis (const unsigned int p)
static ::ExceptionBase &  ExcInUse (int arg1, std::string arg2, std::string arg3)
static ::ExceptionBase &  ExcNoSubscriber (std::string arg1, std::string arg2)
Protected Member Functions
void  transform_into_standard_form ()
Static Protected Member Functions
static void  scale (std::vector< double > &coefficients, const double factor)
static void  shift (std::vector< double > &coefficients, const number2 shift)
static void  multiply (std::vector< double > &coefficients, const double factor)
Protected Attributes
std::vector< double >  coefficients
bool  in_lagrange_product_form
std::vector< double >  lagrange_support_points
double  lagrange_weight
Private Types
using  map_value_type = decltype(counter_map)::value_type
using  map_iterator = decltype(counter_map)::iterator
Private Member Functions
std::vector< double >  compute_coefficients (const unsigned int p)
void  check_no_subscribers () const noexcept
Private Attributes
std::atomic< unsigned int >  counter
std::map< std::string, unsigned int >  counter_map
std::vector< std::atomic< bool > * >  validity_pointers
const std::type_info *  object_info
Static Private Attributes
static std::mutex  mutex
Lobatto polynomials of arbitrary degree on [0,1]
.
These polynomials are the integrated Legendre polynomials on [0,1]. The first two polynomials are the standard linear shape functions given by \(l_0(x) = 1x\) and \(l_1(x) = x\). For \(i\geq2\) we use the definition \(l_i(x) = \frac{1}{\Vert L_{i1}\Vert_2}\int_0^x L_{i1}(t)\,dt\), where \(L_i\) denotes the \(i\)th Legendre polynomial on \([0,1]\). The Lobatto polynomials \(l_0,\ldots,l_k\) form a complete basis of the polynomials space of degree \(k\).
Calling the constructor with a given index k
will generate the polynomial with index k
. But only for \(k\geq 1\) the index equals the degree of the polynomial. For k==0
also a polynomial of degree 1 is generated.
These polynomials are used for the construction of the shape functions of Nédélec elements of arbitrary order.
Definition at line 466 of file polynomial.h.

privateinherited
The data type used in counter_map.
Definition at line 230 of file subscriptor.h.

privateinherited
The iterator type used in counter_map.
Definition at line 235 of file subscriptor.h.
Polynomials::Lobatto::Lobatto  (  const unsigned int  p = 0  )
Constructor for polynomial of degree p
. There is an exception for p==0
, see the general documentation.
Definition at line 759 of file polynomial.cc.

static
Return the polynomials with index 0
up to degree
. There is an exception for p==0
, see the general documentation.
Definition at line 850 of file polynomial.cc.

private
Compute coefficients recursively.
Definition at line 764 of file polynomial.cc.

inlineinherited
Return the value of this polynomial at the given point.
This function uses the most numerically stable evaluation algorithm for the provided form of the polynomial. If the polynomial is in the product form of roots, the evaluation is based on products of the form (x  x_i), whereas the Horner scheme is used for polynomials in the coefficient form.
Definition at line 108 of file polynomial.h.

inherited
Return the values and the derivatives of the Polynomial at point x
. values[i], i=0,...,values.size()1
includes the i
th derivative. The number of derivatives to be computed is thus determined by the size of the array passed.
This function uses the Horner scheme for numerical stability of the evaluation for polynomials in the coefficient form or the product of terms involving the roots if that representation is used.
Definition at line 121 of file polynomial.cc.

inlineinherited
Return the values and the derivatives of the Polynomial at point x
. values[i], i=0,...,n_derivatives
includes the i
th derivative. The number of derivatives to be computed is determined by n_derivatives
and values
has to provide sufficient space for n_derivatives
+ 1 values.
This function uses the most numerically stable evaluation algorithm for the provided form of the polynomial. If the polynomial is in the product form of roots, the evaluation is based on products of the form (x  x_i), whereas the Horner scheme is used for polynomials in the coefficient form.
The template type Number2
must implement arithmetic operations such as additions or multiplication with the type number
of the polynomial, and must be convertible from number
by operator=
.
Definition at line 143 of file polynomial.h.

inlineinherited
Similar to the function above, but evaluate the polynomials on several positions at once, as described by the array argument points
. This function is can be faster than the other function when the same polynomial should be evaluated on several positions at once, e.g., the x,y,z coordinates of a point for tensorproduct polynomials.
The template type Number2
must implement arithmetic operations such as additions or multiplication with the type number
of the polynomial, and must be convertible from number
by operator=
.
Definition at line 161 of file polynomial.h.

inlineinherited
Degree of the polynomial. This is the degree reflected by the number of coefficients provided by the constructor. Leading nonzero coefficients are not treated separately.
Definition at line 171 of file polynomial.h.

inherited
Scale the abscissa of the polynomial. Given the polynomial p(t) and the scaling t = ax, then the result of this operation is the polynomial q, such that q(x) = p(t).
The operation is performed in place.
Definition at line 181 of file polynomial.cc.

staticprotectedinherited
This function performs the actual scaling.
Definition at line 271 of file polynomial.cc.

inherited
Shift the abscissa oft the polynomial. Given the polynomial p(t) and the shift t = x + a, then the result of this operation is the polynomial q, such that q(x) = p(t).
The template parameter allows to compute the new coefficients with higher accuracy, since all computations are performed with type number2
. This may be necessary, since this operation involves a big number of additions. On a Sun Sparc Ultra with Solaris 2.8, the difference between double
and long double
was not significant, though.
The operation is performed in place, i.e. the coefficients of the present object are changed.
Definition at line 200 of file polynomial.cc.

staticprotectedinherited
This function performs the actual shift
Definition at line 278 of file polynomial.cc.

inherited
Compute the derivative of a polynomial.
Definition at line 206 of file polynomial.cc.

inherited
Compute the primitive of a polynomial. the coefficient of the zero order term of the polynomial is zero.
Definition at line 213 of file polynomial.cc.

inherited
Multiply with a scalar.
Definition at line 219 of file polynomial.cc.

inherited
Multiply with another polynomial.
Definition at line 225 of file polynomial.cc.

inherited
Add a second polynomial.
Definition at line 231 of file polynomial.cc.

inherited
Subtract a second polynomial.
Definition at line 237 of file polynomial.cc.

inherited
Test for equality of two polynomials.
Definition at line 243 of file polynomial.cc.

inherited
Print coefficients.
Definition at line 249 of file polynomial.cc.

inlineinherited
Write or read the data of this object to or from a stream for the purpose of serialization using the BOOST serialization library.
Definition at line 258 of file polynomial.h.

virtualinherited
Return an estimate (in bytes) for the memory consumption of this object.
Definition at line 264 of file polynomial.cc.

staticprotectedinherited
Multiply polynomial by a factor.
Definition at line 284 of file polynomial.cc.

protectedinherited
Transform polynomial form of product of linear factors into standard form, \(\sum_i a_i x^i\). Deletes all data structures related to the product form.
Definition at line 292 of file polynomial.cc.

inherited
Subscribes a user of the object by storing the pointer validity
. The subscriber may be identified by text supplied as identifier
.
Definition at line 136 of file subscriptor.cc.

inherited
Unsubscribes a user from the object.
identifier
and the validity
pointer must be the same as the one supplied to subscribe(). Definition at line 156 of file subscriptor.cc.

inlineinherited
Return the present number of subscriptions to this object. This allows to use this class for reference counted lifetime determination where the last one to unsubscribe also deletes the object.
Definition at line 300 of file subscriptor.h.

inlineinherited
List the subscribers to the input stream
.
Definition at line 317 of file subscriptor.h.

inherited
List the subscribers to deallog
.
Definition at line 204 of file subscriptor.cc.

privatenoexceptinherited
Check that there are no objects subscribing to this object. If this check passes then it is safe to destroy the current object. It this check fails then this function will either abort or print an error message to deallog (by using the AssertNothrow mechanism), but will not throw an exception.
Definition at line 53 of file subscriptor.cc.

protectedinherited
Coefficients of the polynomial \(\sum_i a_i x^i\). This vector is filled by the constructor of this class and may be passed down by derived classes.
This vector cannot be constant since we want to allow copying of polynomials.
Definition at line 302 of file polynomial.h.

protectedinherited
Stores whether the polynomial is in Lagrange product form, i.e., constructed as a product \((xx_0) (xx_1) \ldots (xx_n)/c\), or not.
Definition at line 308 of file polynomial.h.

protectedinherited
If the polynomial is in Lagrange product form, i.e., constructed as a product \((xx_0) (xx_1) \ldots (xx_n)/c\), store the shifts \(x_i\).
Definition at line 314 of file polynomial.h.

protectedinherited
If the polynomial is in Lagrange product form, i.e., constructed as a product \((xx_0) (xx_1) \ldots (xx_n)/c\), store the weight c.
Definition at line 320 of file polynomial.h.

mutableprivateinherited
Store the number of objects which subscribed to this object. Initially, this number is zero, and upon destruction it shall be zero again (i.e. all objects which subscribed should have unsubscribed again).
The creator (and owner) of an object is counted in the map below if HE manages to supply identification.
We use the mutable
keyword in order to allow subscription to constant objects also.
This counter may be read from and written to concurrently in multithreaded code: hence we use the std::atomic
class template.
Definition at line 219 of file subscriptor.h.

mutableprivateinherited
In this map, we count subscriptions for each different identification string supplied to subscribe().
Definition at line 225 of file subscriptor.h.

mutableprivateinherited
In this vector, we store pointers to the validity bool in the SmartPointer objects that subscribe to this class.
Definition at line 241 of file subscriptor.h.

mutableprivateinherited
Pointer to the typeinfo object of this object, from which we can later deduce the class name. Since this information on the derived class is neither available in the destructor, nor in the constructor, we obtain it in between and store it here.
Definition at line 249 of file subscriptor.h.

staticprivateinherited
A mutex used to ensure data consistency when printing out the list of subscribers.
Definition at line 271 of file subscriptor.h.
